6
7
(optional) To extend the height of the fan,
connect the male pins of the extension tube to
the female connectors on the base and lower
side of the motor. To release the tube, press
the buttons on the bottom and back side.
5
Fit the supplied screw to the underside of the
grill and connect the two halves rmly together.
6
Attach the motor to the connector input on the
base unit. Refer to point 7 for attachment of
extension tube.
motor
base
