DV Mark DV Micro 50 - Technical Specifications; Amplifier Channels and Controls; Output and Feature Summary; Physical and Power Requirements

6
Channels: Two (clean / lead)
Controls: Level (clean ch)
Drive / Level (lead ch)
EQ Controls: Bass - Mid - High (clean ch)
Bass - High (lead ch)
Speaker Outputs: Two ¼” Jacks mono out 8 ohm
Power Output: 60W @ 4ohm / 45W @ 8ohm
Other Features: Footswitch input for channels switch
AUX IN
Headphone OUT
XLR Line OUT with GND Lift
Dual Voltage selector 120V/240V
Dimensions: 200 x 64 x 221 mm / 7.87” x 2.51” x 8.7”
Weight: 1,9 kg / 4.19 lbs
POWER REQUIREMENT: 100V; 120V; 230V; 240V - 50/60Hz
BLOCK DIAGRAM
TECHNICAL SPECS
Input
Drive
Power
Power
Out
TONES
Line out
Level
Level
TONES REVERB
AUX
