12
Channels: Three
Controls: Gain - Level - Presence - Master
EQ Controls: Low - Mid - High
Speaker Outputs:
. . . . . . . .Two ¼” Jack mono out 4/16 ohm
. . . . . . . .One Neutrik Speakon/¼” Jack Combo BRIDGE out
8/16 ohm
Power Output: 250W + 250W @ 4ohm, 150W + 150W @ 8ohm,
85W + 85W @ 16 ohm;
500W@8ohm, 300W@16ohm (BRIDGE mode)
Other Features:
. . . . . . . .Virtual amps
. . . . . . . .Speaker cabs and microphones
. . . . . . . .Effects
. . . . . . . .External memory (SD card)
Dimensions: 486 x 89 x 324 mm / 19” x 3.5” x 12.76”
Weight: 4,3 kg / 9.48 lbs
POWER REQUIREMENT: 100V; 120V; 230V; 240V - 50/60Hz (Voltage is factory preset according to region of sale).
DV Mark amps/combos are manufactured to be sold and used in the country of purchase, and they are factory preset to at country’s voltage.
Due to homologation issues, the voltage may not be changed.
TECHNICAL SPECS
BLOCK DIAGRAM
