2) Start by running the wiring
up into the engine bay avoiding
any moving components install
the solid inner half rst. (part
without the DV8 logo on it) Se-
cure is with the factory bolt on
top.
1) Remove the factory fend-
er/liner assembly by un-
screwing all 10mm bolts from
the liner area. Remove the
push-in rivets on the lower
poron of liner to release it
from the frame. Li up on
the fenders to separate from
the snap-in clips on the body
4) The arm will go behind the bulk
head that the liner is up against.
This picture is illustrang the ap-
proximate locaon the arm need to
be resng at.
3) Next take the arm that comes
with the parts kit and place it behind
the panel. Needs to be in the orien-
taon in the picture. Threaded part
of the nutsert facing the motor. You
should have a right and le arm.
