DVS 16 - Continuous and Event Recording Settings

35
 There are three kinds of recording mode.
- Continuous: record continuously.
- Event: record only when Sensor or Motion calls.
- Emergency: record when press EMERGENCY key.
 The Continuous menu will allow user to set recording mode.
 Each frame on Title column shows camera title registered in DEVICES>Camera/PTZ. User cannot change camera titles
here.
 Click ( ) each frame on Resolution column to select recording resolution of a corresponding camera. User may select one
of 720x480, 720x240 and 360x240. (NTSC)
 Click ( ) each frame on Frames column to select recording rate of a corresponding camera. Recording rate varies by
camera. Below lists the maximum recording rate of each camera.
NTSC(PAL) 360x240 720x240 720x480
4 Channel DVR
120(100) 120(100) 60(50)
8 Channel DVR
240(200) 120(100) 60(50)
16 Channel DVR
480(400) 240(200) 120(100)
 Click ( ) each frame on Quality column to select recording quality of a corresponding camera. User may select one of
Super, High and Std.
 User may change the setting values of Resolution, Frames, Quality at a time by clicking the menu tab.
 Choose ‘OK’ to confirm the setting.
 Please click ( ) Event and the following screen will appear.
 The Event menu will allow user to set Event videos.
 Each frame on Title column shows camera title registered in DEVICES>Camera/PTZ. User cannot change camera titles
here.
 Click ( ) each frame on Resolution column to select recording resolution of a corresponding camera. User may select one
of 720x480, 720x240 and 360x240. (NTSC)
 Click ( ) each frame on Frames column to select recording rate of a corresponding camera. Recording rate varies by
Event
Continuous
