Model No. V1365T
Camera TYPE Color/BW Anti-Vandal Day/Night PIXIM Dome Camera
Mount Surface
Image Device PIXIM CMOS
Size 1/3"
Pixels-Total 742(H) x 552(V)
Pixels-Effective 720(H) x 540(V)
Scanning System 525 line, 2:1Interlace
Horizontal Frequency Internal Mod 15,734Hz
Vertical Frequency Internal Mode 59.94Hz
Min. Scene Illumination F1.2 0.08 Lux [TDN 0.01 Lux]
Functions WDR ON
AGC ON/OFF (Gain Adjust)
AWB ATW / AWB / Manual
Lens Focal Length 3.3 ~ 12mm (3.6x Optical)
Resolution Horizontal 540 TV Lines [at TDN (B/W) :570 TV Lines]
Video Output VBS 1.0Vp-p VBS 1.0Vp-p(75 Load)
S/N Ratio S/N Ratio 48dB
OSD OSD YES
Environmental Conditions Operating Temperature
-10℃ ~ +55℃(14℉ ~ 131℉)
Humidity Less than 90%
Power Power Requirement 12VDC/24VAC
Power Consumption
12VDC: 190mA
24VAC: 165mA
Physical Specification Dimensions(φ x H) 145 x 109.6mm
