Dwell 145576 - Base Leveling and Wall Anchoring

Ix16 pcs
(17*16*11)
Hx16 pcs
(M3*18)
Ex6 pcs
(Ø15*12)
UP
DOWN
E
I
H
WARNING:
THE WALL TIE IS SUPPLIED TO ATTACH THE PRODUCT TO THE WALL.PLEASE ENSURE THE CORRECT
FIXING PLUG IS USED FOR THE TYPE OF WALL.IF YOU ARE UNSURE,WE RECOMMEND YOU CONSULT A
PROFESSIONAL.
live like this
Produced in China for Dwell UK
14 of 15
www.dwell.co.uk
live like this
20
21
AI-P1021WA
Jx2 pcs
(M4*25)
Kx2 pcs
(M4*16)
Lx4 pcs
(Ø12*Ø4*1.5)
Mx2 pcs
(Ø6*25)
Nx2 pcs
(20*1.5*200)
90°
90°
N
M
J
L
K
N
L
H+30mm
If the floor is not even,
you can adjust the feet
height to ensure the
base panel to be even.
Notch wardrobe
three door with drawers
