Dwyer Instruments Love Controls 16010 User Manual

949-1239-3 34 Rev. 10/98
Input Ranges (Field Selectable)
Thermocouple Types
Input
Type
Range
1°F
1°C
Type J or L*
-100 to +1600
-73 to +871
Type K*
-200 to +2500
-129 to +1371
Type T*
-350 to +750
-212 to +398
Type E*
-100 to +1800
-73 to +982
Input
Type
Range
1°F
1°C
Type R
0 to 3200
-17 to +1760
Type S
0 to 3200
-17 to +1760
Type B
+75 to 3308
+24 to 1820
Type C
0 to 4208
-17 to 2320
Input
Type
Range
1°F
1°C
Type N*
-100 to +2372
-73 to +1300
RTD Types Option 965
Input
Type
Range
1°F
1°C
100 Ohm
Platinum
0.00385 DIN
Curve*
-328 to +1607
-200 to +875
100 Ohm
Platinum
0.00392 Nist
Curve*
-328 to +1607
-200 to +875
120 Ohm
Nickel
0.00628 US
Ind. Curve*
-112 to +608
-80 to +320
1000 Ohm
Platinum
0.00385 Nist
Curve*
-328 to +1607
-200 to +875
Process Input Types
* These Input Types can be set for 0.1° display.
If temperature goes above 999.9° or less than
-199.9° the display will return to whole degree
resolution.
The 0 to 20 mAdc, 4 to 20 mAdc, 0 to 10 Vdc, 2 to 10 Vdc, and -10 to +10
mVdc inputs are fully scalable from a minimum of 100 counts span placed
anywhere within the within the range of -1999 to +9999. Decimal point
position is adjustable from the zero place (9999), tenths (999.9), hun-
dredths (99.99), thousandths (9.999), or ten thousandths (.9999).
