Using This Product Installing This Product
Checking the Toilet
1. Measure the size of the toilet.
Depending on the size of the toilet, it may not be
possible to mount this product on it.
Make sure the toilet's dimensions are as shown in
the figure on the right.
2. Conditions for using water supply
hose (included)
The length of the water supply hose included with
this product is 37.40" (950 mm), but a length of
31.50" (800 mm) from the junction fitting to the
seat unit's water supply socket is appropriate.
(Refer to the figure on the right)
31.50" (800 mm)
or less
18.50" (470mm) or more
5.51" to 6.18"
(140 to 157 mm)
15.35" (390 mm)
or less
5.91" (150 mm) or more
1.97" (50mm) or more
