Dyna-Flo DFC User Manual

Model
DFC Valve Actuator
Operation, Parts and Instruction Manuals
Dyna-Flo Control Valve Services Ltd.
Edmonton, Alberta, CANADA
Website: www.dynaflo.com
Phone: 780
• 469 • 4000
Toll Free: 1 • 866 • 396 • 2356
Fax: 780 • 469 • 4035
Instruction Manual May 2007
9 Upper Diaphragm Plate (2 Piece Design)
Zinc Plated Steel
10 Travel Stop
Steel
(See Table 3, Page 17)
11 Actuator Stem Hex Head Bolt
Zinc Plated Steel
(See Table 3, Page 17)
12 Hex Head Cap Screw
Zinc Plated Steel
Size 1069 & 2069 (Qty. 6) H5CZ38.034
Size 2105, 2156, H5CZ38.034
3105, 3156
(Qty. 8)
Size 3220 (Qty. 12) H5CZ12.100
13 Gasket
Composition
Size 1069 & 2069 1E80120402D
Sizes 2105, 2156, 1E84540402D
3105,3156
Size 3220 (O-Ring Nitrile) 1D26910699D
14 Snap Ring
SST
Size 1069 & 2069 1E80133702D
Size 2105, 2156, 1E84563899D
3105, 3156, 3220
15 Bushing
Brass
Size 1069 & 2069 1E68281401D
Size 2105, 2156, 1E84571401D
3105, 3156
Size 3220 1N1316X005D
16 O-Ring
Buna (Qty. 2)
Size 1069 & 2069 1D23750699D
Size 2105, 2156, 1C56220699D
3105, 3156
Size 3220 1E73690699D
17 O-Ring
Buna
Size 1069 & 2069 1C41570699D
Size 2105, 2156, 1E84580699D
3105, 3156, 3220
18 Hex Head Cap Screw (casing)
Zinc Plated Steel
Size 1069 & 2069 (Qty. 16) H5FZ38.100
Size 2105 & 3105 (Qty. 20) H5FZ38.100
Size 2156 & 3156 (Qty. 24) H5FZ38.100
Size 3220 (Qty. 28) H5FZ38.114
Parts
Key Description Part Number
1 Yoke
Cast Iron
Size 1069 3E88461904D
Size 2069 3E82081904D
Size 2105 & 2156 3E90081904D
Size 3105 & 3156 3E84591904D
Size 3220 3N13031904D
2 Spring
Steel
(See Table 4, Page 18)
3 Stem
17-4
Size 1069 3E8847X174D
Size 2069 2E8209X174D
Size 2105 & 2156 2J3328X174D
Size 3105 & 3156 2E8461X174D
Size 3220 2N13172174D
Size 3220-4 21A3812X01D
4 Lower Diaphragm Casing
Steel
Size 1069 & 2069 2E68262506D
Size 2105 & 3105 3E84532506D
Size 2156 & 3156 3E84772506D
Size 3220 & 3220-4 2N13102506D
5 Upper Diaphragm Casing
Steel
Size 1069 & 2069 2E68142899D
Size 2105 & 3105 3E84462899D
Size 2156 & 3156 3E84672899D
Size 3220 2N12782899D
6 Lower Diaphragm Plate
Steel
Size 1069 & 2069 1F88582409D
Size 2105, 2156, 1F89094402D
3105, 3156
Size 3220 1N13152409D
7 Diaphragm
Nitrile / Nylon
Size 1069 & 2069 2E66990220D
Size 2105 & 3105 2E85960220D
Size 2156 & 3156 2E85980220D
Size 3220 2N13090220D
8 Upper Diaphragm Plate
Cast Iron
Size 1069 & 2069 31B2029904D
Size 2105 & 3105 41B2030904D
Size 2156 & 3156 2E84751904D
Size 3220 2N12701904D
