Dyna-Flo DFC User Manual

Dyna-Flo Control Valve Services Ltd.
Edmonton, Alberta, CANADA
Website: www.dynaflo.com
Phone: 780
• 469 • 4000
Toll Free: 1 • 866 • 396 • 2356
Fax: 780 • 469 • 4035
Model
DFC Valve Actuator
Operation, Parts and Instruction Manuals
Instruction Manual May 2007
Size 2069, 2105, 2156 1A41322412D
Size 3105, 3156, 3220 1A37542412D
29 Jam Nut
Steel Pl.
Size 1069 1P13122414D
Size 2069, 2105, 2156 1A35372412D
Size 3105, 3156, 3220 1A35112412D
30 Vent Cap
Plastic Y602-1BD
31 Valve Stem
32 Yoke Nut
33 Actuator Name Plate
34 Travel Stop Cap
Brass
Type3
Size 1069 & 2069 1F59781401D
Size 2105, 2156, 1H11111401D
3105, 3156
Size 3220 1R38761401D
Type 4
Size 1069 & 2069 1F59781401D
Size 2105, 2156, 1F83961401D
3105, 3156
Size 3220 1R38761401D
Steel
Type 4
Size 1069 & 2069 1F59782409D
35 Travel Stop Body
Cast Iron
Type 3
Size 1069 & 2069 1K72351901D
Size 2105, 2156, 2K72301901D
3105, 3156
Size 3220 2U14181902D
Type 4
Size 1069 & 2069 37A9437X01D
Size 2105, 2156, 37A9432X01D
3105, 3156
Size 3220 37A9661X01D
36 Casing-Mounted Travel Stop
Steel
(See Table 5, Page 19)
15
Parts
Key Description Part Number
19 Hex Nut (casing)
Zinc Plated Steel
Size 1069 & 2069 (Qty. 16) NHFZ38
Size 2105 & 3105 (Qty. 20) NHFZ38
Size 2156 & 3156 (Qty. 24) NHFZ38
Size 3220 (Qty. 28) NHFZ38
20 Spring Seat
Steel Pl.
Size 1069 & 2069 1R17992312D
Size 2105, 2156, 1R18002312D
3105, 3156
3220 1N12961905D
21 Spring Adjuster
Steel Pl.
Size 1069 & 2069 1E82102410D
Size 2105, 2156, 1E84622410D
3105, 3156
Size 3220 1N13181X01D
22 Stem Connector Assembly
Steel Pl.
Size 1069 18A1243X01D
Size 2069 18A1668X01D
Size 2105 & 2156 18A1671X01D
Size 3105 & 3156 18A1672X01D
Size 3220 18A1675X01D
23 Stem Connector bolt
Part of Stem Connector Assembly (Qty. 2)
24 Travel Scale
SST
(See Table 3, Page 17)
25 Machine Screw
SST (Qty. 2)
Size 1069, 2069, 2105, 2156 1E79323899D
Size 3105, 3156, 3220 1E83133899D
26 Speed Nut
SST (Qty. 2) 242-206
27 Travel Disk
SST
Size 1069 1E79313899D
Size 2069, 2105, 2156 1E80753899D
Size 3105 & 3156 1E83283899D
Size 3220 1B97183899D
28 Stem Nut
Steel Pl.
Size 1069 1P13122414D
