Dyna-Flo DFC User Manual

Model
DFC Valve Actuator
Operation, Parts and Instruction Manuals
Dyna-Flo Control Valve Services Ltd.
Edmonton, Alberta, CANADA
Website: www.dynaflo.com
Phone: 780
• 469 • 4000
Toll Free: 1 • 866 • 396 • 2356
Fax: 780 • 469 • 4035
Instruction Manual May 2007
43 Lock Washer
Steel
Size 1069 & 2069 1A48782899D
Size 2105, 2156, 1A87322899D
3105, 3156
Size 3220 1A54932898D
44 Elbow Vent
Plastic
Size 1069, 2069, 2105, 27A5516X01D
2156, 3105, 3156
Size 3220 17A6572X02D
Parts
Key Description Part Number
37 Travel Stop Screw
Steel
Type 5
Size 1069 & 2069 1F75373513D
Size 2105, 2156, 1K13113513D
3105, 3156
Size 3220 13A2133X01D
38 Travel Stop Nut
Brass
Type 4
Size 1069 & 2069 18A2303X01D
Size 2105, 2156, 18A1272X01D
3105, 3156
39 Extension Rod (Stem)
Steel
Type 3
Size 1069 & 2069 1F75363503D
Size 2105, 2156, 1J23273503D
3105, 3156
Size 3220 1V7764X00AD
Bronze
Type 4
Size 1069 & 2069 27A9655X01D
Size 2105, 2156, 27A9656X01D
3105, 3156
Size 3220 27A9763X01D
40 Hex Head Jam Nut
Zinc Plated Steel
Size 1069 & 2069 1A35372412D
Size 2105, 2156, 1A35112412D
3105, 3156, 3220
41 Hex Nut
Zinc Plated Steel
Type 3
Size 1069 & 2069 1A41322412D
Size 2105, 2156, 1A37542412D
3105, 3156, 3220
42 Hex Head Cap Screw
Zinc Plated Steel
Type 3
Size 1069, 2069, 2105, 1A36842405D
2156, 3105, 3156
Size 3220 1N12932899D
Type 4
Size 1069, 2069, 2105 1A36842405D
2105, 2156, 3105, 3156
16
