DFC Valve Actuator
Operation, Parts and Instruction Manuals
Instruction Manual May 2007
17
Table 3
Keys 10, 11 & 24 Actuator Stem Hex Head Bolt, Travel Stop and Travel Scale
Actuator Size Travel inch (mm) Hex Head Bolt Travel Stop Travel Scale
1069
3/4 (19) 1R4089X004D 1R40952409D 1E79363999D
1-1/8 (29) 1R4091X003D 1R40962409D 17A9814X01D
2069
3/4 (19) 1R4089X004D 1R40952409D 1E80813899D
1-1/8 (29) 1R4091X003D 1R40962409D 1E80823899D
1-1/2 (38) 1R4092X002D 1R40972409D 1E80833899D
2105
3/4 (19) 1R4098X002D 1R41052409D 1E80813899D
1-1/8 (29) 1R4099X002D 1R41082409D 1E80823899D
1-1/2 (38) 1R4101X002D 1R41062409D 1E80833899D
2 (51) 1R4102X001D 1R41072409D 1R44453898D
2156
3/4 (19) 1R4098X002D 1R41052409D 1E80813899D
1-1/8 (29) 1R4099X002D 1R41082409D 1E80823899D
1-1/2 (38) 1R4101X002D 1R41062409D 1E80833899D
2 (51) 1R4102X001D 1R41072409D 1R44453898D
3105
3/4 (19) 1R4098X002D 1R41052409D 1E83313899D
1-1/8 (29) 1R4099X002D 1R41082409D 1E83323899D
1-1/2 (38) 1R4101X002D 1R41062409D 1E83333899D
2 (51) 1R4102X001D 1R41072409D 1E83343899D
3156
3/4 (19) 1R4098X002D 1R41052409D 1E83313899D
1-1/8 (29) 1R4099X002D 1R41082409D 1E83323899D
1-1/2 (38) 1R4101X002D 1R41062409D 1E83333899D
2 (51) 1R4102X001D 1R41072409D 1E83343899D
3220
3/4 (19) 1R4110X001D 1R41162409D 1H74573899D
1-1/8 (29) 1R4110X001D 1R41152409D 1H74583899D
1-1/2 (38) 1R4098X002D 1R41142409D 1H74593899D
2 (51) 1R4099X002D 1R41132409D 1H74603899D
3 (76) 1R4102X001D 1R41072409D 1H74613899D
