Model
DFC Valve Actuator
Operation, Parts and Instruction Manuals
Instruction Manual May 2007
3
Table 1
Model DFC Actuator Specifications
SPECIFICATION
ACTUATOR SIZE
1069 2069 2105 2156 3105 3156 3220
(1)
Nominal Effective
Area
inch2 69 69 105 156 105 156 220
cm2 445 445 667 1006 677 1006 1419
Yoke Boss
Diameter
inch 2-1/8 2-13/16 2-13/16 2-13/16 3-9-16 3-9/16 3-9/16
mm 54 71 71 71 90 90 90
Acceptable Valve
Stem Diameter
inch 3/8 1/2 1/2 1/2 3/4 3/4 3/4
mm 9.5 12.7 12.7 12.7 19.1 19.1 19.1
Maximum Allowable
Output Thrust
lb 2300 2700 5650 7550 5650 6800 8800
N 10,230 12,010 25,131 33,582 25,131 30,246 39,142
Maximum
Travel
(2)
Standard
inch 1-1/8 1-1/2 22223
(3)
mm 29 38 51 51 51 51 76
Top-Loaded
inch 3/4 --- 3/4 --- --- 1-1/8 ---
mm 19 --- 19 --- --- 29 ---
Maximum Casing
Pressure for Actuator
Sizing
(4,5)
Psig70706555655550
kPag 483 483 448 379 448 379 345
Maximum Excess
Diaphragm Pressure
(4)
Psig20201010101010
kPag 138 138 69 69 69 69 69
Maximum Diaphragm
Casing Pressure
(4,5)
Psig90907565756560
kPag 621 621 517 448 517 448 414
Approximate Weight
lbs 48 50 90 121 94 122 254
Kg 22 23 41 55 43 55 115
Material
Temperature
Capabilities
Nitrile Elastomers -40 to 180
o
F (-40 to 82
o
C)
Silicone Elastomers -65 to 300
o
F (-54 to 149
o
C)
NOTES:
1 These values also apply to the DFC Size 3220-4 actuator.
2 Actuator travel may be less than the value listed after connected to the valve.
3 Maximum actuator travel for the 3220-4 is 4 inches (102 mm).
4 See Specification section for definitions.
5 This Maximum Casing Pressure is not to be used for normal operating pressure. Its purpose is to allow for
typical regulator supply settings and/or relief valve tolerances.
