Dyna-Glo DGB515SDP - Page 5

5
PACKAGE CONTENTS
B
C
D
A
H
G
E
F
I
J
K
L
N
O
M
P
Q
R
V
T
S
U
PART DESCRIPTION QUANTITY
A Hood Handle 1
B Temp Gauge 1
C Grill Body Assembly 1
D Control Knob 6
E Grease Pan 1
F Grease Cup 1
G Warming Rack 1
H Cooking Grate 3
I Heat Tent 5
J Left Side Table Assembly 1
K Side Burner Rack 1
L Side Burner 1
M Right Side Burner Body 1
N Control Knob Bezel 1
PART DESCRIPTION QUANTITY
O Left Leg Assembly 1
P Leg End Cap 2
Q Cylinder Block Bar 1
R Cart Rear Support 1
S Bottom Shelf’s Rear
Bracket Assembly 1
T Cart Front Panel - Upper 1
U Cart Front Panel - Lower 1
V Right Leg Assembly 1
W Bottom Shelf 1
X Axle 1
Y Wheel 2
Z Bottom Shelf’s Front
Bracket Assembly 1
W
Y
X
Z
D
