Figure 3-5 The front of the computer with the display panel open
1. Web Camera 8. Wireless communication antennas
(not shown)
2. Web Camera LED 9. Display hinge
3. Microphones 10. Power button
4. Display screen 11. Keyboard
5. NUM LOCK indicator 12. Touch Pad
6. CAPS LOCK indicator 13. Touch Pad control buttons
7. Power indicator 14. Fingerprint sensor*
* Provided with some models.
Product appearance depends on the model you purchased.
Web Camera Web Camera is a device that allows you to
record video or take photographs with your
computer. You can use it for video chatting or
video conferences using a communication tool.
Web Camera LED The Web Camera LED glows when the Web
Camera is operating.
Do not point the web camera directly at the sun.
User's Manual 3-6
