9. Carefully fasten the 01447 Housing in a vise with aluminum or bronze jaws so that the rotor
spindle is pointing up. Notice: Over tightening vise will damage housing.
As needed, install fabric silencer around the exhaust control spacer and o-rings around
the lock ring.
Apply Loctite #7649 Primer to the thread of the lock ring.
Apply a small amount of Loctite #567 or equivalent to the lock ring.
Use the 50971 Lock Ring Tool and a torque wrench to install the lock ring.
T to 34 N·m/~300 in. lbs.
T to 34 N·m/~300 in. lbs.
Loctite #567
