Dynabrade 40324 - Page 5

4. Fasten the 96346 Bearing Separator (2") around the 01013 Cylinder. Place the separator
and the motor in the 96232 Arbor Press (#2) so that the rotor spindle is pointing down.
Use a 3/16" or 5 mm diameter flat end drive punch to push the rotor out of the 01015
Bearing.
96346 Bearing Separator
