Dynabrade Grinder Series - Step 2: Assemble Front End Plate Components

2. Install 54909 Shim into 54901 Front End Plate.
! Select .003" (~0.08 mm) shim thickness from 94910 Shim Pack and install into
front end plate.
! Install 01787 O- Ring into outside diameter groove of plate.
! Install 54900 Bearing all the way into plate.
Shims
54909 Shim
01787 O-Ring
54900 Bearing
