Dynacraft BALANCE CYCLE User Manual

9
SEAT ASSEMBLY AND ADJUSTMENT
STEP 1. Loosen hex nut on keyed bolt of seat clamp (see Figure 12).
STEP 2. Insert the seat post into the seat clamp on the frame to the minimum
insertion mark (see Figure 13).
STEP 3. Tighten the hex nut on keyed seat clamp bolt securely
(see Figure 14).
NOTE: The proper seat height is achieved when your child can put both feet
on the ground at the same time when seated. Adjust the seat height if too high
or too low.
WARNING: IMPORTANT NOTE
The seat post must be insert to at least the “minimum insertion” line
marked on the seat post.
FIGURE 12 FIGURE 13
MINIMUM
INSERTION MARK
HEX NUT
FIGURE 14
TOP VIEW
MINIMUM
INSERTION
MARK
