Dynamic DX Power Module PMB User Manual

 6SHFLILFDWLRQV
8
 6SHFLILFDWLRQV
(OHFWULFDO
Applicable to both channels. T
amb
= -25 to 50E C, V
BAT
= 24.0 V unless otherwise
specified.
Symbol Parameter Conditions Min Nom Max Units
V
BAT
Battery Voltage 18.0 24.0 32.0 V
V
BSH
"Battery saver" high
threshold
Averaged. Battery
saver enabled
21.0 V
V
BSL
"Battery saver" low
threshold
Averaged. Battery
saver enabled
18.0 V
P
Q
Quiescent power Relay de-energised 2.0 5.0 W
P
SBV
Standby power PM "off" 15 30 mW
T
lim0
Thermal limit I
MO
=0 @ T
lim0
70 EC
I
DXBUS
DXBUS supply
current
Case temp. 20EC12 A
30/HIWDQG5LJKW0RWRU2XWSXWV
Symbol Parameter Conditions Min Nom Max Units
f
PWM
PWM frequency 19.6 kHz
I
MO
Peak motor output
current
Duration 15 seconds.
Initial case
temperature 20
EC.
Current limit
programmed to 60A
54.0 60.0 66.0 A
I
MO
15 minute continuous
motor current
T
amb
= 20°C 23.5 A
V
MO
Max. motor output
voltage
Full conduction, I
MO
= 10A
23.5 V

Dynamic DX Power Module PMB Specifications

General

Brand	Dynamic
Model	DX Power Module PMB
Category	Control Unit
Language	English
