Figure 4
V. Panel Descriptions
For easier assembly, please understand and distinguish the differences between
each panel.
A. Floor Panel
When the FLOOR PANEL faces upward, you will find the floor heat
emitter panel on the topside and towards the front of the FLOOR
PANEL. (see Figure 5)
B. Understanding the Difference Between the Top and Bottom of
the Wall Panels
The (4) panels are in the upright position when the moldings are at
the top. The moldings will be facing inward towards the interior of
the sauna room. You will see the heat emitter cords coming from
the topside of the wall panels. (see Figure 5a)
Molding
Floor Heater
Front of Sauna Room
Figure 5
Figure 5a
