Dynamic TRE-75 TAMPING RAMMER - Page 27

- 26 -
Item
Part
Drawing number
Description
Qty
1
3001
GB/T10-1988
Bolt M10×60
7
2
3002
GB/T10-1988
Bolt M12×80
2
3
3003
GB/T10-1988
Bolt M12×65
2
4
3004
TRE75-01-01-02
Metal sheet
1
5
3005
TRE75-01-01-03
Wooden sheet
1
7
3007
GB/T95-1985
Washer10
7
8
3008
GB/T6182-2000
Nut M10
7
9
3009
TRE75-01-01
Rammer assembly
1
13
3013
TRE75-01-01-01
Kit-roller
1
14
3014
GB/T95-1985
Washer12
2
15
3015
GB/T6182-2000
Nut M12
2
16
3016
Screw M10×1×10
1
17
3017
Oil gauge
1
18
3018
TRE75-01-03
Pipe-protective
1
19
3019
GB/T70.1-2000
Screw M8×20
8
20
3020
TRE75-01-02
Cover
1
21
3021
GB/T6182-2000
Nut M20 ×1.5
1
22
3022
TRE75-02
Slipper
1
25
3025
TRE75-04
Spring
2
26
3026
TRE75-03
Spring
2
