14
PSG 45
GB
seconds.
3) Unplug the power plug from the outlet.
4) Dismantle the spray gun as shown in Fig. 7 (spare parts).
5) Clean all the soiled parts thoroughly.
6) Mount the individual parts in the reverse order.
7) Put a few drops of oil (such as sewing machine oil) into the suction and return holes
(Fig. 6, arrow). Switch the spray gun on briey.
List of accessories/ spare parts (Fig. 7)
Item Designation Order No.
1 Paint container 0500 484
2 Filter with suction tube 0402 703
3 Spare valve 0500 167
4 Circular-section jet nozzle 0.6 mm 0500 232
Environmental protection
The device and all accessories and packaging have to be recycled in an
environmentally friendly manner. Do not dispose of the appliance with
household waste. Support environmental protection by taking the appliance
to a local collection point or obtain information from a specialist retailer.
Leftover paint and solvents may not be emptied into drains, the sewage system
or disposed of as household rubbish. It has to be disposed of separately as special
waste. Please pay special attention to the instructions on the product packaging.
Important information on product liability!
If accessories from other manufacturers are used, liability and warrantee claims may be
partially or completely void. With original PSG 45 accessories and spare parts, compliance
with all safety regulations is guaranteed.
Correction of Malfunctions
Malfunction Cause Remedy
Spray gun hums and does
not function
Piston clogged
Defective drive
Dismantle and clean the pump
Contact your sales point
Spray gun does not suck in No valve in the pump Insert the valve
Spray gun fuctions, but
sprays irregularly
Spray material in the container is
running out
Spray piston is being held skew so
that air is being sucked in.
Sprayed material viscosity too high.
Fine adjustment knob not set
correctly
Tip worn
Valve worn
Incorrect valve inserted
Rell
Hold horizontally
Dilute correspondingly
Adjust to suit the sprayed
material
Replace
Replace
Use the correct valve
