Dynex DX-TVM113 - Package Contents

Package contents
3
DX-TVM113
Package contents
Make sure that you have all the hardware necessary to assemble your new TV wall mount:
A Wall Plate (1)
B Left TV Bracket (1)
C Right TV Bracket (1)
R Wall Plate Template (1)
TV Hardware Bag
DX-TVM113 Wall Plate Template • Gabarit • Plantilla
Note: For wood frame installations, use a stud nder to locate wood
studs rst.
Remarque : Pour une construction à ossature de bois, localiser
d'abord les montants en bois, à l'aide d'un détecteur de montants.
Nota: para la instalación en construcciones de armazón de madera,
primero debe localizar las vigas de madera con un localizador de vigas.
http://san.us/286
Need more information about your mount? Scan this QR code or visit www.dynexproducts.com.
<FR>Need more information about your mount? Scan this QR code or visit www.dynexproducts.com.
<SP>Need more information about your mount? Scan this QR code or visit www.dynexproducts.com.
Tools Needed
Outils nécessaires
Herramientas requeridas
Top
Haut
Parte superior
Top
Haut
Parte superior
V1 13-0140
A
B
C
R
Label Hardware Qty.
D4
E4
F8
G4
H4
I4
J4
K4
M4 × 12 mm
screw
M4 × 30 mm
screw
M4 washer
M6/M8 washer
M4 spacers
M6 × 12 mm
screw
M6 × 20 mm
screw
M6 × 35 mm
screw
Label Hardware Qty.
L4
M4
N4
O4
P4
Q4
M8 × 16 mm
screw
M8 × 40 mm
screw
M6/M8 spacers
Lag bolt washer
5/16" × 2 1/2" lag bolt
Concrete anchor
1 0 20 30 40 50 60 70 80 90 100mm
1234in
