Dynorbital Supreme - Self-Contained Dust Collection Systems; Mini-Reusable Felt Bag; Reusable Felt Bag; Reusable Felt Bag w;Zipper

7
MMaacchhiinnee SSppeecciiffiiccaattiioonnss
Model Motor Motor Dia. Orbit Sound Air Flow Rate Air Pressure Spindle Weight Length Height
Number hp (W) RPM Inch (mm) Level CFM/SCFM (LPM) PSIG (Bars) Thread Pound (kg) Inch (mm) Inch (mm)
56800 .28 (209) 12,000 3/16" (5) 76 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 6 (152) 3-3/4 (95)
56803 .28 (209) 12,000 3/16" (5) 83 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 8-1/4 (210) 3-3/4 (95)
56804 .28 (209) 12,000 3/16" (5) 76 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 7 (178) 3-3/4 (95)
56815 .28 (209) 12,000 3/16" (5) 78 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 6-1/2 (165) 3-5/8 (92)
56818 .28 (209) 12,000 3/16" (5) 81 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 8-1/2 (216) 3-5/8 (92)
56819 .28 (209) 12,000 3/16" (5) 78 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.2 (1.0) 7-1/4 (184) 3-5/8 (92)
56826 .28 (209) 12,000 3/16" (5) 79 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.2 (1.0) 7 (178) 3-1/2 (89)
56829 .28 (209) 12,000 3/16" (5) 79 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.2 (1.0) 9 (229) 3-1/2 (89)
56830 .28 (209) 12,000 3/16" (5) 79 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.2 (1.0) 7-3/4 (197) 3-1/2 (89)
56840 .28 (209) 12,000 3/32" (2) 76 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 6 (152) 3-3/4 (95)
56843 .28 (209) 12,000 3/32" (2) 83 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 8-1/4 (210) 3-3/4 (95)
56844 .28 (209) 12,000 3/32" (2) 76 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 7 (178) 3-3/4 (95)
56850 .28 (209) 12,000 3/32" (2) 78 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 6-1/2 (165) 3-5/8 (92)
56853 .28 (209) 12,000 3/32" (2) 81 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.1 (1.0) 8-1/2 (216) 3-5/8 (92)
56854 .28 (209) 12,000 3/32" (2) 78 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.2 (1.0) 7-1/4 (184) 3-5/8 (92)
56859 .28 (209) 12,000 3/32" (2) 79 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.2 (1.0) 7 (178) 3-1/2 (89)
56862 .28 (209) 12,000 3/32" (2) 79 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.2 (1.0) 9 (229) 3-1/2 (89)
56863 .28 (209) 12,000 3/32" (2) 79 dB(A) 3/18 (510) 90 (6.2) 5/16"-24 female 2.2 (1.0) 7-3/4 (197) 3-1/2 (89)
Additional Specifications: Air Inlet Thread 1/4" NPT • Hose I.D. Size 1/4" or 8 mm
Self-Contained Dust Collection Systems
Easily attach to Dynorbital
®
Supreme Random Orbital Sander – Self-Generated Vac-Ready Models.
50694 Mini-Reusable Felt Bag
• New bag design features a one
micron filter rating. Bag traps over
99% of vacuum particles one
micron or larger.
• Mounts directly to any Vac-Ready
tool or to any exhaust hose.
• Measures 11" long x 3" wide.
End opens up - no need to remove
bag from tool when emptying.
50683 Reusable Felt Bag
• New bag design features a one
micron filter rating. Bag traps over
99% of vacuum particles one
micron or larger.
• Hook ‘n loop end for easy emptying.
• Measures 14-1/2" L x 7-1/2" W.
• Connects to vacuum hose.
56304 Reusable Felt Bag w/Zipper
• New bag design features a one
micron filter rating. Bag traps over
99% of vacuum particles one
micron or larger.
• Has zipper-lock end.
• Measures 14-1/2" L x 7-1/2" W.
• Connects to vacuum hose.
95986 Hose Cover
(5' long cloth cover)
• Covers air line and exhaust/vacuum
hoses (not included).
• Eliminates damage from hoses
dragging on the workpiece.
54290 “Bag-in-Box” System
• 95361 Air Line 5' long.
• 50682 Flex-Hose 1" dia. x 6' long.
• 95362 Rubber Connectors (5, attach
air line to vacuum hose).
• 95575 Durable Box Receptacle (to
house bag and store tool).
• Sample paper bag included.
Paper bag reorder:
50692 (400/case) or
50693 (24 per package.)
50617 & 56303 – 6' Long Flex-Hose
• Both systems include 6' long 50682
Flex-Hose.
• Shown with optional 95361 Air Line
(1/4" diameter).
50617: Has 50683 Standard Reusable
Felt Bag with hook ’n loop
end for easy emptying.
56303: Has 56304 Zipper-Lock Bag.
54284 Mini-Flex-Hose System
• 95580 Air Line 1" dia. x 28" long.
• 50638 Flex-Hose 1" dia. x 18" long.
• 50694 Mini-Reusable Felt Bag.
• 95362 Rubber Connectors (3) which
connect air line to exhaust hose.
