Dyson AB09 - Page 29

Water temperature control
If you are connecting a hot and cold water
feed, you will need to install a thermostatic
mixer (Fig 16, not supplied).
Hot and
cold feed in
Thermostatic
mixer
Desired temperature out
Cold feed in
Heater
Desired temperature out
Fig.16 Fig.17
If you are connecting to cold only water
feed, you will need to install a heater
(Fig 17, not supplied).
WallShort
Long
Installation
