E.C.A. GeliosPlus 11 - Page 11

POSITION DISTANCE (cm) POSITION DISTANCE (cm)
A-Below a windows 60 G-
Next
to vertical or horizontal pipe
60
B- Below
an
air
vent 60
H- Below the distance grille from the outside
30
of the building
C-
Below rain channel
30 I- Distance
from
the inner corner
of the
100
buildina
D- Under
the balcony 30
L- From
the
ground or from
the fioor
180
E- Next
to
a window 40 M- Vertical distance of two fiue outlets 250
F-
Next to
an air
grill
60
N- Horizontal
distance of two fiue
outlets
100
Figure 4b
Figure 4a
9
