ADVANCED PROGRAMMING OPTIONS AND QUICK REFERENCE TABLE.
Need Action
Factory
Default
Response
Buzzer
Enter programming mode Master code + Master code 1234 Chime tone up
Master and user codes
Change master code
*
00 + new master code (4-8 digits) Note the number of digits the
master is set to will be the number of digits all user codes, lock, aux and
bypass.
No chime tone
Set user codes 01 ~ 19 (Lock relay
output only)
*
01~ 19 + new unique user code (Same length as master code)
User 01 =
3333
Chime tone up
Set user codes 20 ~ 39 and 41 ~ 99
(Lock relay output only)
*
6 + 2 digit user number + new unique user code (Same length as
master code)
Chime tone up
Set user code 40 (Aux relay output
only)
*
40 + new unique aux user code (Same length as master code)
9999 Chime tone up
Keypad lockout on multiple incorrect
code attempts.
*
51 to change status on or off.
De-
activated
Chime tone up
Delete a user code or all user codes. (If
deleting all user 01 defaults to 3333)
*
50 + 00 for all, 01 for user 1, 02 for user 2………………….99 for user 99.
Chime tone up
Relays
Select Lock relay type or pulse length.
*
20 + 00 = latch mode or 01 for 1 sec, 02 for 2 sec………99 for 99 sec
1 sec. Chime tone up
Select Aux relay type or pulse length
*
58 + 000 = latch mode or 001 for 1 sec, 002 for 2 sec………..999 for 999
sec.
Latch Chime tone up
Bypass
mode
Enable bypass mode.
*
52 + 1
Disabled Chime tone up
Disable bypass mode.
*
52 + 0
Default Chime tone up
Setup bypass code
*
54 + new unique bypass code
None Chime tone up
Alarm modes
Disable alarm output mode
*
55 + 0
Disabled Chime tone up
Select alarm output to activate on
door forced open condition
*
55 + 1 (Door open time limited to equal Lock relay on time)
Not
selected
Chime tone up
Select alarm output to activate on
tamper switch
*
55 + 2
Not
selected
Chime tone up
Select alarm output to activate on
both door forced and tamper switch
*
55 + 3
Not
selected
Chime tone up
Select Alarm output active time
*
56 + 001 for 1 sec, 002 for 2 sec………..999 for 999 sec.
Chime tone up
Auxiliary modes
Disable Aux output
*
57 + 0
Enabled Chime tone up
Allocate door monitor to work with
Aux output
*
57 + 1
Not
Allocated
Chime tone up
Activate Aux output when multiple
incorrect codes have been entered
*
57 + 2 (Not operational if Aux relay has been set to latch)
Not
Selected
Chime tone up
Activate Aux output when
*
key is
pressed (Doorbell function)
*
57 + 3
Not
Selected
Chime tone up
Activate Aux output when tamper is
activated
*
57 + 4
Not
Selected
Chime tone up
Activate Aux output when door is
forced open
*
57 + 5
Not
Selected
Chime tone up
Activate Aux output together with lock
output
*
57 + 6
Not
Selected
Chime tone up
Aux output only activates when Aux
code is entered
*
57 + 7
Default Chime tone up
Factory
default
Factory default Power down
Place jumper across the system restore pins
Power up Continuous chime
On continuous chime remove jumper and replace it in normal operation
position.
