7
Electric Wheels LLC-888-571-2845 (Toll Free)- 15855 N Greenway Hayden Loop -Suite 190, Scottsdale, AZ 85260
1. Place the Hub Motor into the front fork. Make sure that the side with the brake hub has the washers and nut in the
following sequence: Washer-Fork-Lock Washer-Washer-Nut.(Figure 1) The other side of the hub must have the
Following sequence: Washer-Spacer-Fork-Washer-Nut. (Figure 2)
2.Before you tighten up the nut on the axle, We will need to install the break hub first. Remove the bolt and screw
located on top of the brake hub and place it over the fork attachment.(Figure 1&2)
Front Hub Motor Installation
