User ManualEW-M48
11
1. First read and fully understand this manual.
3. Do not connect any cables before all the parts of the electrical system are mounted.
Do not turn on the wheelchair yet.
1 Installa�on procedure
Warning:
Do not connect the posive terminal (B+) of the baery to the LiNX LE System Power Module unl the
wheelchair is completely wired and ready for tesng as described in the Tesng secon.
Figure 14:
Power OFF
Figure 15:
Power ON
2.1.1 Power up / down
Note:
In the unlikely event that the wheelchair is in a runaway situaon, the user can press the Remote's power buon
to perform an EMERGENCY STOP. See secon 2.1.2 Emergency stop
See also:
2.1.9 The status indicator on page 13
