Page A-3
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 75765-G03 PEDAL BOX ASSEMBLY (INCLUDES ITEMS 2 - 44)........................................ 1
2 70116-G02 ACCELERATOR PEDAL BRACKET ............................................................ 1
3 01051-G01 SCREW, #8 - 16 X 1/2" LG ........................................................................... 4
4 25853-G02 PEDAL BOX AND COVER ........................................................................... 1
5 00684-G6 SCREW, #8 - 32 X 3/4" LG (STAINLESS STEEL) ....................................... 4
6 75652-G01 MICRO SWITCH........................................................................................... 1
7 01050-G02 SCREW, #4 - 20 X 1 1/8" LG ........................................................................ 2
8
9 72066-G01 CONTROL ARM ........................................................................................... 1
10 23860-G1 BEARING...................................................................................................... 2
11 24621-G1 NYLON WASHER, 5/16" .............................................................................. 2
12 12064-G1 PUSH NUT, 5/16" ......................................................................................... 1
13 25768-G01 PIVOT ROD .................................................................................................. 1
14 72199-G01 PIVOT BRACKET ......................................................................................... 1
15 14390-G1 LOCK NUT, 3/8 - 24...................................................................................... 1
16
17 72198-G03 MICRO SWITCH CAM.................................................................................. 1
18 15126-G1 LOCK NUT, 5/16 - 24.................................................................................... 1
19 00487-G3 SETSCREW, 1/4 - 20 X 3/8" LG................................................................... 1
20 72074-G01 CONTROL ARM LINK .................................................................................. 1
21 72225-G01 SHOULDER BOLT, #10 - 24 X 11/16" LG.................................................... 1
22 00532-G4 NUT, 5/16 - 24 .............................................................................................. 2
23 17677-G1 SPRING RETAINER, 1/2"............................................................................. 1
24 17979-G1 ACCELERATOR ROD BUSHING................................................................. 1
25 73046-G01 COMPRESSION SPRING, 3/8".................................................................... 1
26 17677-G2 SPRING RETAINER ..................................................................................... 1
27 72072-G01 ACCELERATOR ROD .................................................................................. 1
28 10385-G4 CLEVIS YOKE (ADJUSTABLE).................................................................... 1
29 10386-G3 CLEVIS PIN, 5/16" X 13/16" LG ................................................................... 1
30 17838-G1 NYLON BUSHING ........................................................................................ 3
