When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page A-4
Service Parts Manual
31 17255-G1 TEFLON WASHER, 5/16"............................................................................. 1
32 10387-G3 COTTER PIN, 3/32" X 3/4" LG ..................................................................... 1
33 70134-G01 PEDAL PIVOT PIN ....................................................................................... 1
34 00986-G01 PUSH NUT, 5/16" ......................................................................................... 1
35 14390-G10 LOCK NUT, #10 - 24..................................................................................... 1
36
37 35679-G02 WIRE HARNESS (PEDAL BOX) .................................................................. 1
38 75639-G01 ACCELERATOR CABLE .............................................................................. 1
39 00559-G8 WASHER, 5/16"............................................................................................ 1
40 25799-G03 ACCELERATOR PEDAL ASSEMBLY (INCLUDES ITEMS 41 - 44) ............ 1
41 27844-G01 ACCELERATOR PEDAL PAD KIT (INCLUDES ITEMS 42 - 43)........... 1
42 15766-G1 OVAL RIVET, 3/16" X 3/8" LG ......................................................... 6
43 * ACCELERATOR PEDAL PAD......................................................... 1
44 * ACCELERATOR PEDAL........................................................................ 1
45 70135-G01 PEDAL PIVOT COVER ....................................................................................... 1
46 00715-G2 BOLT, 5/16 - 18 X 13/16" LG .............................................................................. 4
47
48 00415-G2 BOLT, 1/4 - 20 X 1 1/4" LG ................................................................................. 1
49 00559-G7 WASHER, 1/4" ................................................................................................... 1
50 75679-G01 CHOKE PIVOT LEVER ....................................................................................... 1
51 15944-G1 BALL JOINT ........................................................................................................ 1
52 00734-G5 LOCK NUT, #10 - 32 ........................................................................................... 1
53 75677-G01 BUSHING ............................................................................................................ 1
54 23577-G1 TORSION SPRING ............................................................................................. 1
55 23726-G7 SPACER, 9/16" ................................................................................................... 1
56 14390-G4 LOCK NUT, 1/4 - 20 ............................................................................................ 1
57
58 75651-G01 CHOKE AND GOVERNOR CABLE BRACKET .................................................. 1
59 00566-G2 LOCK WASHER, 7/16"........................................................................................ 2
60 00462-G7 BOLT, 7/16 - 14 X 7/8" LG .................................................................................. 2
ACCELERATOR
