EA3GCY ILER-20 MK2 - PARTS LIST SORTED BY VALUE;QUANTITY

ILER-20 MK2 SSB QRP Transceiver Kit Page 7
PARTS LIST SORTED BY VALUE/QUANTITY
Resistor list
Qty
Value
Checked
Ref.
Identified
5
1
R33, R51, R57, R60, R61
brown-black-gold
1
10
R1
brown-black-black
2
22
R15, R56
red-red-black
4
100
R13, R39, R50, R52
brown-black-brown
1
270
R58
red-violet-brown
2
470
R46, R54
yellow-violet-brown
12
1K
R2, R7, R10, R16, R30, R38, R42, R47, R53, R59, R62, R63
brown-black-red
1
1K2
R45
brown-red-red
1
1K5
R32
brown-green-red
4
4K7
R4, R25, R48, R55
yellow-violet-red
9
10K
R3, R5, R11, R12, R14, R22, R31, R34, R35
brown-black-orange
7
22K
R27, R36, R37, R40, R41, R43, R44
red-red-orange
1
33K
R26
orange-orange-orange
3
47K
R21, R28, R29
yellow-violet-orange
2
56K
R8, R9
green-blue-orange
1
100K
R6
brown-black-yellow
1
150K
R18
brown-green-yellow
1
220K
R20
red-red-yellow
1
270K
R24
red-violet-yellow
2
470K
R17, R19
yellow-violet-yellow
1
1M
R23
brown-black-green
1
1K
P1 RX-gain pot. w/shaft (optional not included)
1K lin.
1
10K
P4 Volume control pot. w/shaft
10K
2
5K
P2, P3 adjustable trimmer
502 or 53E
1
500
P5 adjustable trimmer
501 or 52Y
R65 is 2K2 (red-red-red) if Q14 = 2SC1969 or NO USED if Q14 = 2SC2078 (see bag 9)
Capacitor list
Qty
Value
Checked
Ref.
Identified
35
100n
C1, C2, C3, C9, C12, C14, C15, C22, C23, C24, C28, C29, C31, C32
104 or 0.1
C33, C39, C43, C44, C48, C50, C51, C56, C59, C60, C64, C65, C67,
C70, C71, C72, C73, C75, C77, C78, C82
5
10n
C26, C40, C68, C69, C76
103 or 0.01
5
1n
C34, C47, C55, C57, C66
102 or 0.001
1
470p
C80 Polystyrene
470
2
220p
C79, C81 Polystyrene
220
1
330p
C10
n33 or 331
2
270p
C45, C46
n27 or 271
2
220p
C16, C27,
n22 or 221
6
100p
C52, C53, C4, C6, C61, C63
101
1
47p
C54
47p
2
27p
C7, C83
27P or 27J
7
8p2
C5, C17, C18, C19, C20, C21, C62
8P2
1
220uf
C36 (elec.)
220uf 25v or 35V
5
100uf
C25, C30, C35, C41, C42 (elec.)
100uf 25V or 35V
6
10uf
C8, C11, C37, C38, C49, C74, (elec.)
10uf 25V or 35V
1
1uf
C13 (elec.)
1uf 25V, 35V or 63V
1
120p
CV1 Murata trimmer BFO
Black
1
160p
CV2+CV3 dual Polyvaricon gang. Tuning. 160p + 70p
70p
