moving to prevent vehicle tilting.
F. Minimum hoist height is 110mm and it is applicable to maintenance of high-grade car.
G. High load bearing chain, safe and reliable.
H. 24V safety voltage control for electric series
I. Imported hydraulic components in use.
The company reserves the right to modify the products without further notice.
Chapter II: Main Technical Parameters
Basic parameters for equipment:
Name
Model
Technical parameter
Rated load
(Kg)
Rising and
falling time
Hoist height Hydraulic
oil
Electric
power
Rated oil
pressure
(1) 3500/4000
4060S
PP N46# 2.2KW 15-16Mpa
(2) 3500/4000
4060S
PP N46# 2.2KW 15-16Mpa
Note: 1. Voltage: The motor with different voltages can be selected in accordance with client’s
requirements.
Single-phase/three-phase: 110V/380V 60Hz
Single-phase/three-phase: 220V/380V 50Hz (standard configuration)
2. The pump station of 220V is adopted and the user must provide power stabilizer to
make sure that motor and related electrical components are not damaged for
undervoltage.
3. The hydraulic oil may differ much in different regions and seasons. It is proposed
that No.46 wear-resistance hydraulic oil be used in 10  40 䉝㻌㼍㼚㼐㻌㻺㼛㻚㻌ʿ
wear-resistance hydraulic oil be used in ˉ510 䉝㻚
4. Environmental requirement:
Working temperature: ˉ 5
䉝 +40䉝 Relative humidity: Temperature +30䉝,
UHODWLYHKXPLGLW\
Transport storage temperature: -25
䉝+55䉝 Altitude in use: Up to 2,000m
The noise of the machine in operation shall be below 80dB (A).
~
