Eagle Eagle-2000 - Mounting the Eagle Power I; Mounting Dimensions and View

INSTALLATION OF THE E-I PS
17 1/2"
15"
REAR VIEW OF CONTROL BOX
MOUNTING BRACKETS
MOUNTING BRACKETS
7"12 3/8"
16 1/2"
3"
(Drawing N.T.S.)
Mounting Holes 3/8" Diameter
MOUNTING THE EAGLE POWER I
(OC)
(OC)
