User manual E&P HYDRAULICS
1.2 Specific features of the Remote control (continued)
EXPLANATION: LEDS
(1) SLOPE IS TO In this position the caravan cannot be levelled,
STEEP as the ground on which it is standing is too uneven.
Switch over if necessary to manual control.
(2) INSUFFICIENT The battery has insufficient power.
VOLTAGE Or the voltage is inadequate to carry out the
procedure safely.
(3) WITHDRAW The caravan is too high at the front end, the front
FRONT WHEEL wheel must be withdrawn. The LED will go out.
(4) SUPPORT NOT One or more of the supports extended has not
WITHDRAWN been completely withdrawn.
(9) MANUAL Adjusting the caravan to a level position can be
OPERATION carried out manually.
(15) BATTERY 9V - Battery power remote control is low.
POWER
(14) LEVEL This indicates that the caravan is now positioned
horizontally.
EXPLANATION: BUTTONS
(5) ON / OFF Switching the system on and off.
(6) MANUAL Switching the system in manual mode,
OPERATION levelling the caravan manually.
(7) AUTOMATIC Switching the system in automatic mode,
OPERATION levelling the caravan goes automatically.
(8) WITHDRAW Withdraw all supports automatically.
ALL SUPPORTS
(10) LEFT SIDE Controls extension of the left-hand-side supports.
(11) REAR END Controls extension of the rear end supports.
(12) FRONT END Controls extension of the front end supports.
(13) RIGHT SIDE Controls extension of the right-hand-side supports.
4.
