E&P HYDRAULICS LEVEL SYSTEM - Page 6

74
›
STEP 1 Fitting the corner supports
1. Removal of the old corner supports
2. Degreasing the floor and the new corner supports
3. Apply adhesive (e.g. Sika 221) to the top surface of the aluminium guide-rails for the new corner
supports. Do not forget to apply to the two aluminium filler plates.
4. Fully tighten one of the three fixing screws.
8
Schritt1
1.DemontagederaltenEckstützen
2.EntfettendesBodensundderneuenEckstützen
3.Kleber(z.B.:Sika221)anderOberseitederAluminium-Laufschieneder
neuenEckstützenauftragen.DabeidürfendiebeidenFüllplattenaus
Aluminiumnichtvergessenwerden.
4.FestzieheneinerderdreiBefestigungsschrauben.
1
3
2
4
