SUBWOOFER CONNECTION (continued)
Low Level (RCA) Connection
This is the best way to deliver an audio signal to the
Supern ova MKIV. Noawadays, most signal
processors/receives are equipped with built-in pre-
amplifier outputs (RCA) which include a subwoofer
output.
There are multiple options to connect the MKIV using the
low level (RCA) connection.
Option 1. Connecting to a Receiver with SUB/LFE
Output
Option 2. Connecting to a Receiver with Full Range
Stereo Outputs
Option 3. Connecting the LINE OUT RCAs to
another amplifier that powers satellite
speakers (front or rear).
SUPERNOVA MKIV USER’S MANUAL
RECEIVER/AMPLIFIER RCA OUTPUT
SUB / LFE
OUT
OUTPUT
LR
MKIV
LOW LEVEL (RCA)
CONNECTION
SUB / LFE
OUT
OUTPUT
LR
RECEIVER/AMPLIFIER RCA OUTPUT
MKIV
LOW LEVEL (RCA)
CONNECTION
SUB / LFE
OUT
OUTPUT
LR
RECEIVER/AMPLIFIER SPEAKER OUTPUT
INPUT
LR
RCA INPUT OF THE AMPLIFIER
POWERING SATELLITE SPEAKERS
MKIV
LOW LEVEL (RCA)
CONNECTION

EarthQuake Supernova MKIV-10 Specifications

General

Brand	EarthQuake
Model	Supernova MKIV-10
Category	Subwoofer
Language	English
