OWNERS MANUAL
Tiller/Cultivator, 13.5 Amp
Copyright All Rights Reserved.
Model TC70016
Thank you for your purchase.
DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING,
ASSEMBLY, PARTS, SERVICE QUESTIONS? GO TO
AMERICANLAWNMOWER.COM OR CALL 1-800-633-1501. BETWEEN 8
AM 5 PM EST, MONDAY-FRIDAY FOR ASSISTANCE.
SAVE THIS MANUAL FOR FUTURE REFERENCE
This product has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the owners manual before
using this product.

Questions and Answers

  • B
    barbarachaseJul 29, 2025
    What to do if my EarthWise TC70016 Tiller motor does not start?
    • W
      wendyhancockJul 29, 2025
      If the EarthWise Tiller motor doesn't start, first ensure the unit is properly plugged in and that there is electricity available from the power supply. Check the cable for any defects, repairing or replacing it if necessary. Also, the safety switch/plug might be defective, requiring professional repair. Finally, the overheat protection may have activated; allow the motor to cool down for approximately 15 minutes before attempting to use it again.
  • S
    Scott HuynhAug 5, 2025
    What to do if my EarthWise Tiller gives poor results?
    • N
      noconnorAug 6, 2025
      If you're getting poor results with your EarthWise Tiller, it might be because the working depth is too small; try setting it to the correct working depth. Another reason could be worn blades, in which case you should replace them.
  • H
    hannahdiazAug 12, 2025
    Why is my EarthWise TC70016 Tiller making abnormal noises?
    • G
      Gail NelsonAug 12, 2025
      If your EarthWise Tiller is making abnormal noises, first switch it off and wait for the tines to come to a complete stop, then remove any jammed objects, as the blade may be jammed. If the noise persists, it could be due to a lack of lubrication, requiring tiller repair (contact customer service at 1-800-633-1501 for assistance). Also, check if bolts, nuts, or other components are loose and tighten them. If noises continue after tightening, arrange for repair.
  • J
    Jeffrey LongAug 20, 2025
    How to fix abnormal vibrations in my EarthWise TC70016 Tiller?
    • S
      Sheryl BrownAug 20, 2025
      If your EarthWise Tiller is experiencing abnormal vibrations, it could be due to damaged or worn blades, which should be replaced. Another possible cause is that the working depth is too large; set the tiller to the correct working depth.

Summary

Important Safety Warnings

General Safety

Replacement Parts

Use only identical replacement parts for servicing to ensure proper function and safety.

Polarized Plugs

Explains the polarized plug feature for correct connection to avoid electric shock.

Extension Cord Requirements

Details type, condition, and gauge for outdoor extension cords to prevent overheating.

General Safety Precautions

Guard Placement

Warns against operating the tiller/cultivator without guards in place to prevent injury.

Tine Safety

Keep hands/feet away from blades and body parts/clothing away from rotating tines.

Risk of Cut

Advise wearing gloves and caution during cleaning/maintenance; ensure tines stop before work.

Assembly Instructions

Operating Instructions

Operating Techniques

Maintenance

Troubleshooting

Parts and Service

EarthWise TC70016 Specifications

General IconGeneral
Tilling Width16 inches
Tilling Depth8 inches
Number of Tines4
Handle TypeAdjustable
Warranty2 years
Engine TypeElectric
Forward Rotating TinesYes
