OWNERS MANUAL
CORDLESS 20 VOLT CULTIVATOR LITHIUM-ION BATTERY PACK
Copyright. All Rights Reserved.
Model TC70020
Your cordless tiller has been engineered and manufactured to our high standard for dependability, ease of operation,
and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the owners manual before
using this product.
Thank you for your purchase.
DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING,
ASSEMBLY, PARTS, SERVICE QUESTIONS? GO TO
WWW.AMERICANLAWNMOWER.COM OR CALL 1-800-313-5111
BETWEEN 8:00 AM—5:00 PM EST FOR ASSISTANCE.
SAVE THIS MANUAL FOR FUTURE REFERENCE
CA Compliant
Charger Included
(Model No.
CHL82000)
3189723
BATTERY MUST BE
CHARGED BEFORE FIRST
USE. TWO TO THREE INITIAL
CHARGING/ DISCHARGING
CYCLES MAY BE REQUIRED
TO ACHIEVE MAXIMUM RUN
TIME/CAPACITY.

Questions and Answers

  • P
    paul96Aug 3, 2025
    What to do if my EarthWise Lawn and Garden Equipment makes abnormal noises?
    • W
      William DanielAug 3, 2025
      If your EarthWise Lawn and Garden Equipment is making abnormal noises, there could be several reasons: * A tine may be jammed. If so, switch off the equipment and wait until the tines come to a complete stop, then remove any jammed objects. * The lubrication may be running out, in which case the tiller/cultivator must be repaired. * Bolts, nuts, or other components might be loose. Tighten all components. If the noises continue, arrange for repair.
  • M
    Melissa ConnerAug 14, 2025
    Why won't my EarthWise Lawn and Garden Equipment run?
    • J
      Jaclyn KellyAug 14, 2025
      If your EarthWise Lawn and Garden Equipment won't run, there are several potential causes: * The battery may not be making contact. Check that the battery is fully inserted. * The trigger switch might not be operational. Ensure that the lock-off button is fully depressed before moving the trigger. * The battery may not be installed correctly. Double-check the battery installation. * The battery may not be charged. Verify the battery charging requirements.
  • S
    Spencer BlankenshipAug 25, 2025
    What to do if my EarthWise Lawn and Garden Equipment has abnormal vibrations?
    • C
      Calvin ColemanAug 25, 2025
      If your EarthWise Lawn and Garden Equipment is vibrating abnormally, consider these possibilities: * The tines may be damaged or worn. Replace any damaged or worn tines. * The working depth might be too large. Adjust the working depth accordingly.

Summary

Safety Instructions

General Safety Guidelines

Covers pre-operation checks, environmental hazards, proper attire, and safe practices.

Operational Hazards and Precautions

Addresses risks from moving parts, foreign objects, vibrations, and inclines.

Assembly Instructions

Battery Installation and Removal

Procedure for inserting and removing the battery pack from the unit.

Operating the Cultivator

Starting and Stopping Procedures

How to safely turn the tiller/cultivator on and off.

Charging the Battery Pack

Maintenance and Troubleshooting

Tine Removal and Installation

Step-by-step guide for replacing the cultivator tines.

Common Problems and Solutions

Troubleshooting guide for issues like unit not running or poor results.

EarthWise TC70020 Specifications

General IconGeneral
BrandEarthWise
ModelTC70020
CategoryLawn and Garden Equipment
LanguageEnglish
