EarthX ETZ5G - Specifications; Model: ETZ5 G; Model: ETZ14 C

E T X S E R I E S L I T H I U M B A T T E R I E S
5
Specifications
Model: ETZ5G
Voltage
13.2 V
Ah (lead-acid equivalent)
10
Ah (1 hour discharge rate)
3.4 (1C rate)
Pulse Crank Amps (PCA)
240A (3 sec @ 20 °C, voltage >7.2V)
Cold Crank Amps (CCA)
140A (modified SAE test, 3 sec@ 0°F,
voltage >7.2V)
Max Continuous Discharge Amps
30A
Standard Charge Voltage
13.9 - 14.6 V
Recommended Charger/Maintainer
Amps
.8 - 5A
Max Charge Amps
15A (from vehicle charging system)
Life (Charge cycles)
4000 cycles @ 1C discharge rate, 25°C
(20% depth of discharge)
2000 cycles @10C discharge rate, 25°C
(80% depth of discharge)
Life (Years)
8 Years
Weight
1.17 lb. (.53Kg)
Dimensions
3.54in x 1.96in x 3.54in
(90mmX50mmX90mm)
Environmental Rating (resistance to
water intrusion)
IP 66 (wash down with a high-pressure
washer)
Operating Temperature
-30 °C to +60 °C
Storage Temperature
-40 °C to +70 °C
Model: ETZ14C
Voltage
13.2 V
Ah (lead-acid equivalent)
20
Ah (1 hour discharge rate)
6.8 (1C rate)
Pulse Crank Amps (PCA)
690A (3 sec @ 20 °C, voltage >7.2V)
Cold Crank Amps (CCA)
330A (modified SAE test, 3 sec@ 0°F,
voltage >7.2V)
Max Continuous Discharge Amps
60A
Standard Charge Voltage
13.9 - 14.6 V
Recommended Charger/Maintainer
Amps
.8 - 10A
Max Charge Amps
30A (from vehicle charging system)
Life (Charge cycles)
4000 cycles @ 1C discharge rate, 25°C
(20% depth of discharge)
2000 cycles @10C discharge rate, 25°C
(80% depth of discharge)
Life (Years)
8 Years
Weight
2.5 lb. (1.1Kg)
