EasyPro ECF10 - UV Sleeve Replacement and Cleaning

8. Useacleanclothto
removetheUVlightby
gentlypullinguponthe
UVbulb.(seegure7)
9. Do not touch the bulb
with your ngers.
10.Carefullyremovethe
blackprotectoronthe
endofthebulb.Install
theblackprotectoron
theendofthenewUV
lightbulb.(seegure8)
11.Carefullyinstallthenew
UVbulbinthebase,besuretouseacleanclothtoinstall
thenewbulb.Pressthebulbrmlyintothebaseuntilyou
hereaclick.(seegure7)
12.Carefullyslidethenewbulbintothesleeveandscrewthe
capintoplace.
13.Reattachthecordretainerclipwiththetwoscrews.
14.If you have an ECF25U or an ECF40UsettheUVcover
backontopofthepressurelterandtightenthethree
screws.
15.If you have an ECF10Umakesuretolineupthepower
cordinthebackwiththeslotintheUVcover.Besureto
lineupthetwoslotsinthefrontoftheUVcoverwiththe
twoprongsbehindthedischargeconnection.Pushdown
ontheUVcoverandlineupthearrowontheUVcoverwith
thearrowontheretainingring.(seegure9)
16.TwisttheUVhousingbacktodesiredpositionandtighten
thescrewsdownontheretainingring.
UV Sleeve Replacement and Cleaning
1. Makesuretheunitisdisconnectedfromthepowersource.
2. Unscrewthebarbedttingsfromtheinletandoutletonthe
lter.
3. Loosenthescrewsonthetopretainingring.Removethe
screws.Theretainingringshouldnowbeloose.(seegure
1)
4. RemovetheUVcoverandsetaside.(seegure3)
5. Removethetwoscrewsandtheplasticretainerclipthat
holdthecordinplaceandsetaside.(seegure5)
6. UnscrewtheUVlightandcarefullyremovefromthehous
-
ing.(seegure10)
7. CarefullysettheUVbulbaside,beingcarefulnottotouch
theUVbulb.
Figure9
Figure10
Figure11
4
Figure7
Figure8
