36
835B35A
Page 14Page 25
Guidance and Manufacturer’s Declaration - Electromagnetic Emissions
The EasyStand Zing is intended for use in the electromagnetic environment specified below. The customer or the user of
the EasyStand Zing should assure that it is used in such an environment.
Emissions Test
RF emissions CISPR 11
Group 1 The EasyStand Zing uses RF energy only for its inter-
nal function. Therefore, its RF emissions are very low
and are not likely to cause any interference in nearby
electronic equipment.
The EasyStand Zing is suitable for use in all establish-
ments, including domestic establishments and those
directly connected to the public low-voltage power
supply network that supplies buildings used for do-
mestic purposes.
Compliance Electromagnetic Environment - Guidance
RF emissions CISPR 11
Class B
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/
Flicker emissions
IEC 61000-3-3
Complies
Guidance and Manufacturer’s Declaration - Electromagnetic Immunity
The EasyStand Zing is intended for use in the electromagnetic environment specified below. The customer or the user
of the EasyStand Zing should assure that it is used in such an environment.
Immunity Test
Electrostatic
Discharge (ESD)
IEC 61000-4-2
± 8 kV contact
± 15 kV air
± 8 kV contact
± 15 kV air
Floors should be wood, concrete, or ceramic tile. If
floors are covered with synthetic material, the rela-
tive humidity should be at least 30 %.
Mains power quality should be that of a typical com-
mercial or hospital environment.
IEC 60601
Test Level
Electromagnetic Environment - Guidance
Electrical Fast
Transient/Burst
IEC 61000-4-4
± 2 kV for power
supply lines
± 1 kV for input/
output
lines
Surge
IEC 61000-4-5
± 1 kV line(s) to
line(s)
± 2 kV line(s) to
earth
Compliance
Level
± 2 kV for power
supply lines
± 1 kV for input/
output
lines
± 1 kV line(s) to
line(s)
± 2 kV line(s) to
earth
Mains power quality should be that of a
typical commercial or hospital environment.
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines
IEC 61000-4-11
<5 % U
T
(>95 % dip in U
T
)
for 0,5 cycle
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip in U
T
)
for 25 cycles
<5 % U
T
(>95 % dip in U
T
)
for 5 s
<5 % U
T
(>95 % dip in U
T
)
for 0,5 cycle
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip in U
T
)
for 25 cycles
<5 % U
T
(>95 % dip in U
T
)
for 5 s
Mains power quality should be that of a typical
commercial or hospital environment. If the user of
the EasyStand Zing requires continued operation
during power mains interruptions, it is recommended
that the EasyStand Zing be powered from an uninter-
ruptible power supply or a battery.
Power frequency
(50/60 Hz) magnetic
field
IEC 61000-4-8
30 A/m
30 A/m Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical
commercial or hospital environment.
NOTE: U
T
is the a.c. mains voltage prior to application of the test level.
34. Place the push handle for the tray onto
the support brackets as shown.
35A. Line up holes on support brackets
and push handle. Insert bolts and tighten
securely.
35B. Repeat steps 33-35 for other side of
tray.
36. If the tray with the arms was ordered,
place the tray upside down as shown. Flip
the chrome arms as shown, remove 4 bolts
from bottom of the tray. Place arm brackets
onto tray and line up holes in arm bracket
with holes on the tray. Insert 4 bolts and
tighten securely. If the swing-away tray was
ordered, skip to step 39.
34
If a Prone model was ordered, skip to step 43.
Prone
Prone
MPS, Supine, TT
To Next Page
