9
7
8
7. Place unit onto its wheels as shown, and
lock casters.
8. If the Gas Spring Lockout was ordered,
unlock the gas spring by pulling the plunger.
(see page 33)
If the Gas Spring Lockout was not ordered,
remove the bolt from the lower part of the
cylinder on the mast as shown, discard bolt.
If the Pow’r Up Lift was ordered, plug the
battery and controller in.
See Fig. B on page 22 for information on
the Pow’r Up Lift.
9. Remove the nut, bolt and two washers
from the brace. These will be used in steps
10-15.
Page 5
