5EATON Series 1 Heavy Duty Hydrostatic Fixed Displacement Motors Parts and Repair E-MOPI-TS002-E September 2004
ITEM REFERENCE
NO. PART NO. QTY. DESCRIPTION PAGES
1 See Table 2.0 1 Output Drive Shaft Subassembly for Motors with Lip Seal XX33-XXX (Current Production) 6
1 See Table 2.1 1 Output Drive Shaft Subassembly for Motors with Face Seal XX31-XXX 6-8
2 See Table 3.1 1 End Cover Subassembly for Motors with Integral Shuttle and Low Pressure Relief Valve 9
3 See Table 4.0, 4.1 1 End Cover for Motors with Valve Block Subassembly 10
3 See Table 4.2 1 Valve Block Subassembly 10
4 See Table 6.0 1 Fixed Motor Housing Subassembly 13
5 See Table 4.0 2 Hex Head Bolt 3/8-16 GR 8 9
6 See Table 4.0 4 Hex Head Bolt 3/8-16 GR 8 9
6 See Table 4.0 6 Hex Head Bolt 3/8-16 GR 8 9
7 See Table 4.0 4 Hex Head Bolt 3/8-16 GR 5 9
8 8775-021 1 Square Cut Seal Ring
9 8765-118 2 O-ring
10 101129-000 2 Back-up Ring
13 103224-000 1 End Cover Gasket (model 33/39/46)
13 103877-000 1 End Cover Gasket (model 54/64)
14 98202-000 3 Dowel Pin (5/16 x 5/8 long)
15 103230-000 1 33/39 Motor Valve Plate
15 104189-000 1 46 Motor Valve Plate
15 105104-000 1 54 Motor Valve Plate
15 105099-000 1 64 Motor Valve Plate
16 See Table 7.0 End Cover Bearing Shims 13
17 See Table 6.0 1 Bearing Cup* 13
18 See Table 6.0 1 Bearing Cone* 13
19 See Table 5.0-5.2 1 Rotating Group Subassembly 12
21 See Table 7.0 1 Seal Kit for Motors with Lip Seal only XX33-XXX (Current Production) 13
21 See Table 7.0 1 Seal Kit for Motors with Face Seal only XX31-XXX 13
23 See Table 7.0 1 Retaining Ring for Lip Seal 13
24 96558-000 2 Lifting Strap (models 33/39/46)
24 96559-000 2 Lifting Strap (models 54/64)
25 103223-000 2 Sealing Washer
31 104511-300 2 Cap Screw, Socket Hd 3/8-16
35 95912-300 2 Cap Screw, Socket Hd 5/16-18
*Cannot be purchased separately.
Parts
Table 1.0 Parts List
