Klicken auf die IP Adresse eine Gerätes
öffnet das Web Interface dieses Gerätes,
so dass an ihm Einstellungen verändert
werden können.
In der Spalte Name wird standardmäßig
die Basic Node-ID des Gerätes angegeben.
Hier kann auch ein sprechender Name
eingetragen werden, der aber eindeutig
sein muss. Hierfür muss rechts das Häck-
chen gesetzt werden. Über „Bearbeiten“
kann nur der Name geändert werden.
Die Spalte Gruppe ist ein zusätzliches
Ordnungskriterium der Liste. Damit lassen
sich Geräte noch einfacher in großen Listen
verwalten. Für den Betrieb des Configura-
tion Server hat dies keine Auswirkungen.
Die Symbole in der Flag Spalte der Liste
zeigen den aktuellen Zustand jedes Gerätes
in Bezug auf den Configuration Server an.
Verwaistes Gerät:
Das Gerät wurde im Netz gefun-
den, ist aber nicht registriert
Statisches Gerät:
Das Gerät wurde manuell als
permanentes Gerät registriert.
Dynamisches Gerät:
Das Gerät hat sich automatisch
selbst am Configuration Server
registriert
Deaktiviertes Gerät:
Das Gerät ist vorübergehend deak-
tiviert, d.h. es erhält keine Nach-
richten mehr über den CEA-852
Channel.
Gespertes Gerät:
Das Gerät ist manuell als Teilneh-
mer deaktiviert, Automatische
Anmeldungen werden nicht mehr
akzeptiert und es werden ihm keine
Informationen über andere Geräte
geliefert.
Clicking on the IP address of a device
opens its the web interface for modify-
ing settings to the device.
The basic node-ID of the device is speci-
fied as standard in the Name column.
A corresponding name can be entered.
This must be unique.
The Group column is an additional
management criterion of the list. This
makes it easier to manage devices in
large lists. This does not affect operation
of the configuration server.
The symbols in the Flag column display
the current condition of each device in
relation to the configuration server.
Orphan Device:
the device was found in the
network but is not registered.
Static Device:
the device has been manually regis-
tered as a permanent device.
Dynamic Device:
the device has registered itself at
the configuration server and can
also be logged off automatically
(see Automatic Registration in
chapter 4.1).
Disabled Device:
the device is temporarily deac-
tivated, meaning it receives no
messages any more via the
CEA-852 channel.
Blacklisted Device:
the device is excluded from
network operation, automatic regis-
trations are no longer accepted and
it receives no information via other
devices.
