Appendix H (b): Inputs/outputs settings tab menu structure continued
DPCT IOM INSTRUCTION OPERATION MANUAL MN124018EN January 2023 www.eaton.com
Appendix H (b): Inputs/outputs settings tab menu structure continued
Inputs/Outputs
Outputs
Select Output
Relay
Select Output
Type
Set Relay ON
Delay Timer
Set Relay OFF
Delay Timer
Enable or Disable
Latch Until Reset
Enable or Disable
F ai ls afe
ote: N Pressing the Back or Cancel button when available will return the screen to the previous option.
