Appendix O: Assembly information
DPCT IOM INSTRUCTION OPERATION MANUAL MN124018EN January 2023 www.eaton.com
Appendix O: Assembly information
Rated voltage, Rated operational voltage, Rated
insulation voltage
Input: 100-240VAC
Output: 12-24VDC
Rated impulse withstand voltage +/- 2.5kV
Rated current of assembly
Input: 6.4A
Output 10A
Rated diversity factor (RDF) 1
Rated Frequency 50/60Hz
Pollution degree of the macro-environment None (Just controller not diesel engine)
Type of earthing system for which the assembly is designed Negative ground polarity
Indoor and/or outdoor installation Unit can be installed both indoors and outdoors
Stationary or moveable Unit is stationary
Degree of enclosure protection Standard offering is UL Type 2, with optional Types 3, 3R, 4, 4X, and 12
Intended for use by ordinary or authorized persons Intended for use by authorized persons
Electromagnetic compatibility classification Emission compliance to Environment B. Immunity compliance to Environment A
Special service conditions No
External design Wall-mounted surface type assembly
Degree of protection against mechanical impact All components protected by a steel enclosure
Type of construction Fixed parts
