General Information
Split Shaft (Muncie)
• Through torque to 21,600 lb-ft.
• Output torque to 936 lb-ft.
• 1410 or 1500 Series companion flange outputs.
• 1500, 1600, 1700, 1800 Series main shaft flanges.
• SAE “B”, “B-B”,”C”, “C-C” and “D” hydraulic
mounts.
• Air-shift operation.
• Suitable for stationary or mobile applications.
• Precision ground gearing for quiet operation.
• Split shaft PTOs can be used on all heavy-duty Fuller® manual, UltraShift PLUS, and AutoShift transmis-
sions.
• Medium-duty wet clutch transmissions will
have split shaft PTO capability with the spring 2006 software
release.
• All other automated products
do not have the ability to operate split shaft PTOs.
